Acoustalay® for Fixed Engineered or Solid Wood Floors

Acoustalay® for
Floated Laminate
or Engineered Floors

Acoustalay® for Fixed
Engineered or
Solid Wood Floors

	Acoustalay® 300 Slatted	Acoustalay® 300+ Slatted	Acoustalay® 1500 Slatted	Acoustalay® 300 Adhesive	Acoustalay® 1500 Adhesive

Key Features	Saves Time & Money
Key Features	The pre-cut slots ensure the floor is glued directly to the sub-floor using minimum, high strength, elastic adhesive			Adhesive backing, (protected by a release liner prior to installation) enables the flooring to be bonded directly to the underlay without the mess & odour of liquid adhesive. Can be walked & worked on immediately after installation.
Flooring Type	Engineered or Solid Wood
Roll sizes	16.5m2, 100m2	16.5m2, 100m2	16.5m2, 150m2	10m2, 100m2	10m2, 150m2
RRP/m2	£5.15	£6.38	£5.45	£8.00	£10.00
10-year protection guarantee
	Medium traffic: Living Room, Kitchen, Hallway	Medium traffic: Coarse Surfaces, Living Room, Hallway	High traffic: Airports & Public areas Acoustic & Heavy loading	Medium traffic: Living Room Kitchen, Hallway	High traffic: Airports & Public areas Acoustic & Heavy loading
	Heavy Domestic /Commercial 3kPa 300Kg/m2	Heavy Domestic /Commercial 3kPa 300Kg/m2	Heavy Commercial 15kPa 1500Kg/m2	Heavy Domestic /Commercial 3kPa 300Kg/m2	Heavy Commercial 15kPa 1500Kg/m2
	28kPa 2800Kg/m2	20kPa 2000Kg/m2	60kPa 6000Kg/m2	28kPa 2800Kg/m2	60kPa 6000Kg/m2
	3mm (2.7mm)	5mm (4.5mm)	2mm (1.8mm)	3mm (2.7mm)	2mm (1.8mm)
	0.088 m2 K/W	0.15 m2 K/W	0.052 m2 K/W	0.088 m2 K/W	0.052 m2 K/W
	Yes	No	Yes	Yes	Yes
	No			No If laid on a concrete sub-floor a separate vapour barrier should be used.

	16dB	18dB	16dB Estimated value	16dB	16dB Estimated value
Installation Guide	Installation Guide			Installation Guide

ACOUSTALAY® for Fixed Engineered or Solid Wood Floors

ACOUSTALAY® Slatted and ACOUSTALAY® Adhesive offer a combination of cushioning support and 100% recovery, giving

With a 10-year protection guarantee ACOUSTALAY® gives you underlay complimenting your floor, from domestic to heavy

Acoustalay® Brochure

Technical Overview

Produced from a unique formula of physically cross-linked polyolefin foam; ACOUSTALAY®

provides; premium quality trade underlay, exceptional all-round performance & insulting spot levelling between the floor & sub-floor - preventing rocking & extending the life of the floor.

A complete, fully tested, and certified range, meeting industry standards exactly.

a market leading “Comfort Walk” foot feel while maintaining its thickness and functional properties for the life of the floor.

commercial uses. Developed for use in acoustically sensitive areas or with underfloor heating; ACOUSTALAY® has the

underlay for your installation.
